DRAGON 9 - Fireplace Insert Anti-Smog Ecofriendly Modern Steel

• Cooperation with mechanical ventilation
  Thanks to the tightness of the entire body and the possibility of connecting air from the outside of the building, the insert can be successfully used in rooms with recuperation (in the case of corner inserts, it requires the use of a single glass).
• Ceramic deflector
  An element of the insert that extends the path of exhaust gases lowers their temperature and causes better afterburning, which makes it possible to recover more heat. Fuel consumption is reduced, and the efficiency of the fireplace increases. The ceramic deflector takes advantage of the high heat capacity of the material used. It stabilizes the temperature of the gases leaving the combustion chamber and maintains their afterburning, which extends the flames. It significantly increases the temperature in the chamber and helps to keep the glass clean.
• Regulation of the combustion process
  The Dragon series inserts are grateless hearths in which the air supply regulating rod is located in the lower part of the façade. Its movement changes the amount and direction of air, and each change of position has a significant impact on the combustion process.
• Clean glass system
  The glass does not get dirty thanks to the use of a proprietary system in which, with the appropriate setting of the slider, air is supplied to the glass by special jets located in the upper part of the façade. The ceramic deflector also helps to keep the glass clean.
• Configurator
  Each model of our insert can be equipped with any selected elements, such as a frame, handle and glass.
• Three types of linings
  The Dragon fireplace can be lined with fireclay (traditional or painted black) or Refrabox ceramics.
• Outside air supply
  The insert is serially equipped with a collector supplying air from outside the building. For ease of installation, connection to the collector is possible from three sides - on the right, left and from the back (after installing it, the other two connections should be covered.

• perfectly clean glass system
• completely sealed insert
• Refrabox ceramic deflector
• air connection on three sides
• fine adjustment of primary/secondary air
• exhaust afterburning system
• configuration (possibility of choosing a frame, handle, masking blend, glass)
• fireclay lining of the firebox
• classic glass in a steel frame
• Classic handle

Additional

• lining the hearth with black chamotte
• lining the hearth with Refrabox ceramics
• combined glass pane, classic, in a steel frame, wide frame
• glass with print (screened)
• aesthetic inox strips on the inside of the frame
• Design handle
